Smooth Bore 1-1/8″ Tapered Nozzle Tip – 2.5″ NHF Swivel Rocker Inlet, 1.5″ NHM Outlet
$229.45
2.5″ Smooth Bore Handline Nozzle Tips with Extending Threads
Our 2.5″ Smooth Bore Handline Nozzle Tips with Extending Threads provide unmatched flexibility and performance. Featuring sizes 1-1/8″ and 1-1/4″, these tips are engineered for superior stream quality and penetration. Made from high-strength aluminum alloy and hard coat anodized, they offer long-lasting durability. The recessed orifice edge and aluminum bumper protect the nozzle, while the laser-engraved pressure and flow chart ensures quick and accurate tip selection. Key Features: Sizes: 1-1/8″ and 1-1/4″ Inlet: 2.5″ NHF Swivel Rocker Outlet: 1.5″ NHM High-Strength Construction: Aluminum alloy with hard coat anodizing Protection: Recessed orifice edge and aluminum bumper for enhanced durability Easy Reference: Laser-engraved pressure and flow chart for quick selection All Prices in USD
The Task Force Tips Smooth Bore 1-1/8″ Tapered Nozzle Tip delivers a concentrated, high-volume smooth bore stream essential for aggressive fire attack. Featuring a 2.5″ NHF Swivel Rocker Inlet, this robust tip integrates rapidly and securely into 2.5-inch hose lines, delivering 270 GPM at 50 PSI (1020 LPM at 350 KPA).
- Optimized Water Delivery: The 1-1/8″ orifice, coupled with a K-Factor of 38.2, ensures a powerful, focused stream, maximizing reach and penetration.
- Seamless Connection: A 2.5″ NHF Swivel Rocker Inlet enables quick, tangle-free attachment to standard hose couplings, enhancing efficiency.
- Modular Adaptability: The 1.5″ NHM Outlet allows direct attachment of additional tips or compatible appliances, offering flexible stream configurations.
- Pure Stream Integrity: Its toothless design guarantees a solid, unbroken stream, critical for effective knockdown and reach.
- Enhanced Maneuverability: Weighing just 1.600 lbs and measuring 7.9″ in length, this compact tip reduces fatigue and improves handling.
This Tapered Nozzle Tip is a vital component for municipal and industrial firefighting, supporting direct attack, master stream setups, and specialized applications where a powerful, precise smooth bore stream is paramount for efficient water application and fire control.
| Color | |
|---|---|
| Nozzle Valve Style |
Ball Valve ,Sold Separately |
| Nozzle Teeth |
Toothless |
| Brand | |
| Shipping Box Dimensions |
10.00 × 10.00 × 6.00 in |
| Weight | |
| Target Nozzle Flow (Imp) |
270 GPM |
| Target Nozzle Flow (Met) |
1020 LPM |
| Target Nozzle Pressure (Bar) |
3 Bar ,3.5 Bar |
| Target Nozzle Pressure (KPA) |
350 KPA |
| Nozzle Type |
Smooth Bore |
| Nozzle K-Factor |
38.2 |
| Nozzle Style |
2-Piece ,Tip Only |
| Nozzle Grip |
None |
| Nozzle Hose Size (Imp) |
2.5" |
| Nozzle Hose Size (Met) |
65 mm |
| Nozzle Hose Connection Type |
NH Female |
| Nozzle Hose Coupling Style |
Rocker Lugs |
| Nozzle Hose Coupling Swivel |
Swivel |
| Nozzle Orifice Size (Imp) |
1-1/8" |
| Nozzle Orifice Size (Met) |
29 mm |
| Product Length (Imp) |
7.9" |
| Product Length (Met) |
20.07 cm |
| Nozzle Outlet Size (Imp) |
1.5" |
| Nozzle Outlet Size (Met) |
38 mm |
| Nozzle Outlet Type |
NH Male |
| Nozzle Outlet Style |
Male Threads |
| Nozzle Outlet Swivel |
Rigid |
| Target Nozzle Pressure (PSI) |
50 PSI |
