Smooth Bore 3/4″ Nozzle Tip – 1.5″ NPSHF Rigid Inlet
1.5″ Smooth Bore Handline Nozzle Tips
Optimize your firefighting capabilities with our 1.5″ Smooth Bore Handline Nozzle Tips. Offering a wide range of sizes from 1/2″ to 1-1/4″, these tips are engineered to deliver exceptional stream quality and penetration. Constructed from robust aluminum alloy and hard coat anodized, they are built to withstand harsh environments. The recessed orifice edge and protective aluminum bumper maintain stream integrity, while the laser-engraved pressure and flow chart ensures you always have the right tip at your fingertips. Key Features: Wide Size Range: 1/2″ to 1-1/4″ Inlet Options: 1.5″ NHF and NPSHF High-Strength Construction: Aluminum alloy with hard coat anodizing Durability: Recessed orifice edge and aluminum bumper for lasting performance Easy Selection: Laser-engraved pressure and flow chart for quick reference All Prices in USD
Out of stock
The Task Force Tips Smooth Bore 3/4″ Nozzle Tip with a 1.5″ NPSHF rigid inlet is engineered to deliver a precise, concentrated water stream for effective fire suppression.
- Delivers a consistent and powerful 120 GPM (450 LPM) stream at 50 PSI (3.5 Bar), optimized for deep penetration and reach.
- An integrated ball valve provides immediate, positive control over water flow and rapid shut-off capability.
- The 1.5″ NPSHF rigid inlet with a knurled coupling ensures a secure, reliable connection to standard hose lines, preventing unwanted rotation.
- Lightweight at only 1.000 lbs (0.45 kg) and compact at 5 inches (12.70 cm) in length, enhancing maneuverability and reducing operator fatigue.
- The toothless smooth bore design produces a solid, unfragmented stream ideal for direct attack and ventilating applications.
Designed for dependable performance, this nozzle is ideal for applications requiring a focused, penetrating stream, such as interior structural firefighting, deep-seated fire attacks, and precise water application in industrial environments. Its robust yet straightforward design ensures reliable operation on the fireground.
| Color | |
|---|---|
| Nozzle Valve Style |
Ball Valve ,Sold Separately |
| Nozzle Teeth |
Toothless |
| Brand | |
| Weight | |
| Target Nozzle Flow (Imp) |
120 GPM |
| Target Nozzle Flow (Met) |
450 LPM |
| Target Nozzle Pressure (Bar) |
3 Bar ,3.5 Bar |
| Target Nozzle Pressure (KPA) |
350 KPA |
| Nozzle Type |
Smooth Bore |
| Nozzle K-Factor |
17 |
| Nozzle Style |
2-Piece ,Tip Only |
| Nozzle Grip |
None |
| Nozzle Hose Size (Imp) |
1.5" |
| Nozzle Hose Size (Met) |
38 mm |
| Nozzle Hose Connection Type |
NPSH Female |
| Nozzle Hose Coupling Style |
Knurled |
| Nozzle Hose Coupling Swivel |
Rigid |
| Nozzle Orifice Size (Imp) |
3/4" |
| Nozzle Orifice Size (Met) |
19 mm |
| Product Length (Imp) |
5" |
| Product Length (Met) |
12.70 cm |
| Target Nozzle Pressure (PSI) |
50 PSI |
