Application A premium-quality, multipurpose industrial hose with a wide range of applications in factories, construction, agriculture, quarries, mines, railroads, the oil and gas industry, and shipbuilding. All sizes are rated at 500 psi (3.4 MPa) maximum working pressure. Nonconductive, minimum electrical resistance greater than one (1) megaohm per inch of hose length at 1000 Volts DC.
Construction Tube Nitrile synthetic rubber, RMA Class A (High Oil Resistance)
Cover Yellow Carbryn™ synthetic rubber, RMA Class A (High Oil Resistance) MSHA approved
Reinforcement Spiral Flexten® yarn, 2″ is braided synthetic yarn
Temperature -20 ºF to 190 ºF (-29 ºC to 88 ºC)
Couplings Contact fitting manufacturer for proper fitting recommendation and coupling procedure.
Branding (example) Gorilla® 1″ (25.4 mm) 500 psi. Made in USA Continental Contitech. Flame Resistant USMSHA No. 2G-14C/14.
