Application Built with a corrugated cover to provide flexibility in petroleum transfer service. A variety of tube compounds are available to tailor the chemical and hydrocarbon resistance of the hose to the type of material handled.
Construction Tube Nitrile synthetic rubber for up to 50% aromatics. Also available with a Flosyn® tube for up to 100% aromatics.
Cover Black Wingprene® synthetic cover, corrugated, wrapped finish
Reinforcement Spiral-plied heavy-duty synthetic fabric with double wire helix
Temperature Range -25˚F to 200˚F (-32˚C to 93˚C)
Packaging Chloroplast heavy-duty packaging
Branding (Spiral) (example) Continental ContiTech Flexdock® 225 psi WP Nitrile Oil Service
Couplings Coupled with standard built-in steel nipple/150#RFSO flanges. Available in other bolt hole patterns, materials and floating flanges on request. Swage nipples are offered up to 10″. Hose assembly is electrically continuous unless otherwise specified by customer.
Non-Stock/Sizes Custom lengths available, contact Customer Service.
- 541-532 (Nitrile tube)
- 541-534 (Flosyn® tube)
Note: Factory coupled hose manufactured according to the code of Federal Regulations Standard 33 CFR 154.500 and 33 CFR 156.170.
